VAS 2.4GHz Pepperbox Xtreme
Designed specifically for the long range wanderer, the Pepperbox offers both high gain (12.5dbic) as well as wide beam width (165degrees!).
90.00 $
Designed specifically for the long range wanderer, the Pepperbox offers both high gain (12.5dbic) as well as wide beam width (165degrees!). No antenna tracker is necessary for this antenna. Just aim in the general direction you intend to fly and go without worrying about aiming the antenna! Vertical coverage on this antenna is somewhat limited (only 60 degrees) so it is not suitable for high altitude runs.
Specifications:
- Frequency Min: 2350MHz
- Frequency Max: 2550MHz
- Gain: 12.5dBi
- Axial Ratio: 1.00
- Radiation pattern: Omnidirectional
- Polarization: Linear
- Flight beam width: 165 degrees
- Impedance: 50Ω
- VSWR: < 2
- Connector type: SMA
