TBS Grinder V4 2207 KV1750
The final form of the botgrinder motors are here! Introducing the v4 grinder motors!
20.99 $
The final form of the botgrinder motors are here! Introducing the v4 grinder motors! Redesigned with the ultimate durability in mind these new motors feature a new bearing reinforcement and a super thicc 4mm shaft to make these the strongest grinder motors yet!
Specification
| Stator Size (Diameter) | 22mm*7mm |
| Kv | 1750kv |
| Magnets | N52SH Curved |
| Windings | 10.5 turn DLRK |
| Shaft Length (mm) | 11.5mm |
| Shaft Diameter (mm) | 4mm |
| Shaft material | Steel |
| Bearing | NSK684 |
| Weight (With Wires) (g) | 34.5g |
| Cells (Lipo) | 4S-6S |
| Max Current (A) | 45A |
| Max Burst Current (A) | 50A |
| Internal Resistance (Rm) | 50Ω |
| Wire Spec (AWG) | 20# |
| Base Mounting Pattern | 16x16mm |
| Base Mounting Thread | M3 Thread |
| Motor Overall Dimensions | φ27.5mm*18.8mm |
